UL 1185

Product Details
Product Description

♦Rated temperature:80℃.Rated voltage:300volts

♦Tinned,annealed,stranded or solid copper xonductor 30~16 AWG

♦Color-coded PVC insulation

♦Tinned copper wire winding

♦Single core PVC coating

♦VW-1SC Vertical flame test

Application

♦Suitable for recording, studio sound systems, electronic circuits

Specification
UL Style
&
CSA Type		 Conductor No.of
Core		 Insulation
Thickness		 Spiral
shield

Jacket
Thickness

 Overall
Diameter		 Standard put-up
Line number Number of wires/diameter Imperial Metric
AWG No./mm Number of core lines mm No.mm mm mm ft/coil m/coil

UL 1185
(Stranded)
绞线

 30 7/0.100 1

MIN AVG
0.38

MIN
0.33

37/0.100

MIN AVG
0.38

MIN
0.31

2.20±0.10 2000 610
28 7/0.127 1 39/0.100 2.30±0.10 2000 610
26 7/0.160 1 41/0.100 2.40±0.10 2000 610
24 11/0.160 1 35/0.127 2.50±0.10 2000 610
22 17/0.160 1 47/0.100 2.60±0.10 2000 610
20 21/0.180 1 47/0.120 2.85±0.10 2000 610
18 34/0.180 1 50/0.120 3.10±0.10 2000 610
