UL 2547

Product Details
Application

UL 2547:

·Conductor using single or multiple tinned soft copper wires

·Semi-rigid PVC insulation

·Tinned copper braid

·PVC coating

·Rated temperature:80℃

·Rated temperature: 80 ℃

·UL VW-1SC & CSA FT2 Vertical flame test

Applications

UL 2547-electronic equipment

Specification
UL Style Conductor Insulation
Thickness		 Spiral
shield

Jacket
Thickness

 Overall
Diameter
Line number Number of wires/diameter
AWG No./mm mm No./mm mm mm

UL 1533
CSA AWM
CLASS I,
GROUP A/B
(1-CORE)

30 7/0.100

0.25

 26/0.102

0.35

 1.7±0.10
28 7/0.127 0.25 29/0.102 0.35 1.8±0.10
26 7/0.160 0.25 32/0.102 0.35 2.0±0.10
24 7*0.20 0.25 35/0.102 0.40 2.2±0.10
22 7*0.25 0.25 41/0.102 0.40 2.4±0.10
20 21/0.178 0.25 36/0.102 0.40 2.4±0.10
UL 2547
CSA AWM
CLASS I/II,
GROUP A/B
(2-CORE)		 30 7/0.100

0.25

 45*0.10 0.40 2.6±0.10
28 7/0.127 0.25 48*0.10 0.40 2.7±0.10
26 7/0.160 0.25 50*0.10 0.40 2.8±0.10
24 7*0.20 0.25 50*0.12 0.40 3.0±0.15
UL 2547
CSA AWM
CLASS I/II,
GROUP A/B
(3-CORE)		 30 7/0.100 0.25 48*0.10 0.40 2.8±0.15
28 7/0.127 0.25 54*0.10 0.40 3.0±0.15
26 7/0.160 0.25 58*0.10 0.40 3.2±0.15
24 7*0.20 0.25 60*0.12 0.40 3.35±0.15
