UL CXTW/XTW, CSA CXWT/PXWT/PXT

Product Details
Product Description

♦Rated temperature:CXWT，PXWT:60℃

♦Rated voltage:CXTW, XTW, PXWT: 300V ，PXT:125V
CXTW:18AWG and 16AWG 300V ，14AWG and 12AWG 300V

♦Conductor using bare copper stranded wire

♦Color-coded PVC insulation

♦CXTW,CXWT:single core twisted pair

♦XTW,PXWT: parallel extrusion

♦VW-1 Vertical flame test

Application

Applicable Christmas light wire set

Specification
UL Style
&
CSA Type		 No.of Core Conductor Insulation
Thickness		 Overall
Diameter		 Stand Put-up
Line number Number of wires/diameter Imperial Metric
AWG （NO./mm） （mm） （mm） ft/coil m/coil
UL XTW
（parallel）		 2 20 26/0.160 0.76 2.5×5.0 2000 610
2 18 41/0.160 0.76 2.7×5.4 2000 610
ULCXTW
(Twisted)		 2 22 17/0.160 0.76 2.3×4.6 2000 610
2 20 26/0.160 0.76 2.5×5.0 2000 610
2 18 41/0.160 0.76 2.7×5.4 1000 305
CSA CXWT
(Twisted)		 2 18 16/0.254 1.14 3.4×6.8 1000 305
2 18 26/0.254 1.14 3.7×7.4 1000 305
CSA PXWT
(Parallel)		 2 18 16/0.254 1.14 3.4×6.8 1000 305
2 16 26/0.254 1.14 3.7×7.4 1000 305
CSA PXT
(Parallel)		 2 20 26/0.160 0.76 2.5×5.0 2000 610
