UL / CSA SPT-1 (W) SPT-2 (W) SPT-3 Parallel Power Cord

Product Details
Product description

♦Rated temperature:60℃、75℃、90℃、105℃

♦Rated voltage:300volts

♦Conductor using bare soft copper stranded wire

♦Wear-resistant PVC insulation

♦Outdoor line: SPT-1W SPT-2W

♦UL VW-1 and CSA FT2 vertical flame resistance test

Application

♦SPT-1R and SPT-2R are suitable for home clocks, fans, radios and various electrical appliances

♦SPT-2W load condition is superior to SPT-1W

♦SPT-3 is used in high load and humid environment, especially suitable for refrigerators and air conditioners

♦UL20288: lighting string connection

Application
UL Style
&
CSA Type		 No.of Core Conductor Insulation
Thickness		 Over
Diameter		 Stand Put-up
Line number Number of wires/diameter Imperial Metric
AWG No./mm mm mm ft/coil m/coil
SPT-1(W/R) 2 18 41/0.160 0.76 2.7×5.4 1000 305
3★ 18 41/0.160 0.76 2.7×8.0 1000 305
SPT-2(W/R) 2 18 41/0.160 1.14 3.4×6.8 1000 305
2 16 65/0.160 1.14 3.7×7.4 1000 305
3★ 18 41/0.160 1.14 3.5×8.6 1000 305
3★ 16 65/0.160 1.14 3.8×9.6 1000 305
SPT-3 2 18 41/0.160 1.52 4.4×8.7 1000 305
2 16 65/0.160 1.52 4.8×9.5 1000 152.5
2 14 41/0.254 2.03 6.0×12.0 500 152.5
2 12 65/0.254 2.41 7.4×14.0 500 152.5
2 10 104/0.254 2.79 9.1×18.2 500 152.5
3 18 41/0.160 1.52 4.4×10.7

1000

 305
3 16 65/0.160 1.52 4.8×11.8 500 152.5
3 14 41/0.254 2.03 6.0×14.5 500 152.5
3 12 65/0.254 2.41 7.4×16.5 500 152.5
3 10 104/0.254 2.79 9.1×18.8 500 152.5
UL20288 2 18 41/0.160 1.02 3.3×5.8 1000 305

★：“R”，“W”Model does not have this specification
