UL NISPT-1 NISPT-2 double insulated parallel power cord

Product Details
Product Description

♦Rated temperature:60℃、75℃、90℃、105℃

♦Rated voltage:300volts

♦导体使用裸软铜绞线

♦环保PVC绝缘及被覆

♦UL VW-1& CSA FT1 Vertical flame test

Application

♦NISPT-1 and NISPT-2 are suitable for home clocks, fans, radios and various electrical appliances

♦NISPT-2 has better load conditions than NISPT-1

Specification
UL Style
&
CSA Type		 No.of Core Conductor Insulation
Thickness
Jacket
Thickness		 Overall
Diameter		 Stand Put-up
Line number Number of wires/diameter Imperial Metric
AWG （NO./mm） （mm） （mm） （mm） ft/coil m/coil
UL NISPT-1 2 18 41/0.160 0.38 0.38 2.8×5.5 3000 305
3 18 41/0.160 0.38 0.38 2.8×8.0 3000 305
UL NISPT-2 2 18 41/0.160 0.76 0.38 3.6×7.0 3000 305
2 16 65/0.160 0.76 0.38 3.9×7.6 3000 305
3 18 41/0.160 0.76 0.38 3.6×10.1 3000 305
3 16 65/0.160 0.76 0.38 4.0×11.0 3000 305
