UL CXTW Single Lighting Cable

Product Details
Product Description

♦Rated voltage:CXTW 300V

♦Conductor using bare copper stranded wire

♦Color-coded PVC insulation

♦Rated thickness: easy to peel, easy to cut

♦Outdoor line: CXTW comply

♦VW-1 Vertical flame test

Application

Applicable Christmas light wire set

Specification
UL Style
&
CSA Type		 Conductor Insulation
Thickness		 Overall
Diameter


Conductor

Resistance at20℃

 Stand Put-up
Line number Number of wires/diameter Imperial Metric
AWG （NO./mm） （mm） （mm） Ω/Kft/（20℃） ft/coil m/coil
ULCXTW 22 17/0.160 0.76 2.3±0.10 16.70 3000 915
20 26/0.160 0.76 2.5±0.10 10.50 3000 915
18 41/0.160 0.76 2.7±0.10 6.64 2000 610
